BelSryup

Specifications:
• syrup spraying system with 1 or 2 vacuum nozzles and 1 or
2 centering devices (custom made)
• height adjustable nozzles
• adjustable spraying angle
• the conveyor can work continuously in one direction or can
take and return the product to the operator
• Proface touchscreen – control panel
• pneumatic material: SMC Pneumatics
• electrical motor: Leroy-Somer
• freq. drive: Omron
• syrup tank 15 L
• conveyor with a polycord belt, width 620 mm
• distance between the bands 30 mm
• diameter of bands 6 mm
• belt speed 1,5-4,5 m/min; 3 m/min at 50 Hz
• open frame construction for easy washing
• stainless steel construction, 3 mm thick
• max pressure 8 bar; air consumption 50 l/min
• 230 V, 50 Hz, 10 A
• length 1200 mm, width 880 mm, height 1550 mm;
